Description
General features
Dual-sided printing (standard)
Reverse transfer printing
Over the edge printing
Color dye sublimation and resin monochrome retransfer
600 dpi print head (23.6 dots/mm)
Bitmap: 24 bits, R/G/B 256 level
Printout: Y/M/C 256 level
64 MB of memory (RAM)
Printing performances
Full card:
Single side (YMCK): 25 s/card – 144 cards/hour
Dual side (YMCKK): 37.5 s/card – 96 cards/hour
Additional encoding modules
Available modules:
Magnetic stripe encoder ISO 7811 (included)
Dual contact and contactless encoder
Encoder connectivity: internal USB hub, 1 port available
Encoding options can be combined
Factory ordered
Interfaces
USB 2.0
Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)
Safety
RFID locking key
Support for security lock (Kensington® type)
Centralized locking system to secure access to blank cards, ribbon and film (optional)2
Card management and specifications
Card feeder: 250 cards (0.76 mm – 30 mil)
Card output hopper: 250 cards (0.76 mm – 30 mil)
Card reject tray: 30 cards (0.76 mm – 30 mil) 3
Card thickness: 0.76 mm (30 mil), manual adjustment
Card types:
PVC cards
Composite PVC cards
PET-F cards
PET-G cards
Polycarbonate cards
ABS cards
Card format: ISO CR80 – ISO 7810 (53.98 x 85.60 mm – 3.370″ x 2.125″)
