Description
MAIN SPECIFICATIONS
Single or Dual sided printing
Single or Dual sided lamination (Flip over)
Color and Monochrome capabilities
Encoding options : magnetic stripes, contact and contactless Smart cards
Supports Windows™, MAC™ and Linux
3-Year Warranty
General Printer Specifications
Color printing module
Standard mode: 300 dpi (dots per inch)
Extended mode: 300×600 dpi (dots per inch)
Extended mode: 300×1200 dpi (dots per inch)
USB connection
Ethernet TCP-IP connection
32 MB RAM
Input hopper capacity: 100 cards (0.76 mm – 30 mil)
Output hopper capacity: 100 cards (0.76 mm – 30 mil)
1-Button and 4-LED control panel
Printer colors: Brilliant Blue or Fire Red
Printer Modes
Color dye sublimation and monochrome thermal transfer
Enhanced color management system for top quality pictures
Near edge-to-edge printing
Integrated ribbon saver for monochrome printing
Printing and Lamination Performance
Personalization throughput will depend on card design and printer settings
YMCK: Single-side printing and lamination: 188 cards/hr(1)
YMCK-K: Dual-side printing and single side lamination: 140 cards/hr(1)
YMCK-K: Dual-side printing and lamination: 110 cards/hr(1)
1/2 YMCK: Single-side printing and lamination: 215 cards/hr(1)
Supported Platforms
Windows™ XP, Vista (32 & 64 bits), and Windows 7 (32 & 64 bits), Windows 8 and 10
Mac™ OS version 10.5 – 10.7
Linux
Available Ribbons
YMCKO: 300 prints/roll
YMCK-K: 200 prints/roll
1/2 YMCKO: 400 prints/roll
1/2 YMCK0-KO: 250 prints/roll (dual-side)
KO: 600 prints/roll
Monochrome Ribbon: 2000 prints/roll
Assorted colored monochrome ribbons (blue, red, green, white, silver, gold): 1000 prints/roll
Available Lamination Film
Clear Continuous Varnish: 1200 prints/roll
Generic Holo Continuous Varnish: 1200 prints/roll
Generic Holo Registered varnish: 1200 prints/roll
Clear Patch 0.5 MIL: 600 prints/roll
Clear Smart Cut Patch 0.5 MIL: 600 prints/roll
Generic Holo Patch 0.6 MIL: 600 prints/roll
Clear Patch 01.0 MIL: 600 prints/roll
Clear Smart Cut Patch 1.0 MIL: 600 prints/roll
Generic Holo Patch 1.0 MIL: 600 prints/roll
Warranty
Use Evolis Genuine products for best performance and extended lifespan of your printer
Printer, print head: 3-year warranty, unlimited number of passes(2)
Reference markers:
1 – Under specific conditions
2 – Subject to observance of specific conditions and use of Evolis genuine consumables.
